SG127 SERIES Safety Pattern Case Pressure Gauge
- Sanitary clamping fastening diaphragm seal
- Standard ISO 2852, DIN 32676
- Wide range hygienic process application
- Double laser welding SS316L diaphragm
- Sterilization and Cleaning in place
- Non-toxic diaphragm filling
- Process temp. -10℃…+130℃. depend on filling
- Accessories capillary, cooling tower.. etc
- Pressure range -1..0, 0..1 up to 40 bar
- Conn. size DIN DN32..DN50, ISO 1 1/2″..2″
Over view :
- Safety pattern case pressure gauge
- Solid front (Baffle wall) with full blow out back
- Accuracy class 0.5
- Dial size 127 mm or 4?”
- Pressure range 0..1, -1..+24 to 0..1000 bar
- Bottom and lower back mounting
- Conn. size G1/4, G1/2″A or NPT
- Index protection IP65
- Ambient/Working temp. -20?..+60?C/Max.+18
- Design material :
Casing– Polypropylene
Wetted parts-Stainless steel
Window-Safety laminated glass
